Model NO.: ARC-160DC
Trademark: GUBANG
Transport Package: Carton
Specification: 420*150*240
Origin: Shenzhen
HS Code: 851539000
Model NO.: ARC-160DC
Trademark: GUBANG
Transport Package: Carton
Specification: 420*150*240
Origin: Shenzhen
HS Code: 851539000
Performance and Features:Â Â Â Â Â
  1.110V/230V dual voltage input. Machine can identify the input voltage automatically.Â
  2. Advanced IGBT inverter technology, nanometer crystal transformer, stable and
reliable.
 3.Over heating protection, over current protection, anti-fluctuation of power voltage.    Â
 4.High duty cycle, high efficiency, low consumption , power saving, ideal DIY welder.
Â
  5.Hot starting, arc force, Anti-sticking, easy arcing, smooth welding and perfect
welding results.
Â
  6.Supplied complete with electrode holder, earth clamp and strong carton box.
Parameter/Specification:

Â
  1.110V/230V dual voltage input. Machine can identify the input voltage automatically.Â
  2. Advanced IGBT inverter technology, nanometer crystal transformer, stable and
reliable.
 3.Over heating protection, over current protection, anti-fluctuation of power voltage.    Â
 4.High duty cycle, high efficiency, low consumption , power saving, ideal DIY welder.
Â
  5.Hot starting, arc force, Anti-sticking, easy arcing, smooth welding and perfect
welding results.
Â
  6.Supplied complete with electrode holder, earth clamp and strong carton box.
Parameter/Specification:
| Model Item      |
ARC-160DC | |
| Voltage(V) | 1~AC110V | 1~AC230V |
| Frequency(Hz) | 50-60 | 50-60 |
| Input Power(KVA) | 5.3 | 6.8 |
| No-load Voltage(V) | 56 | 56 |
| Current Range(A) | 20-130 | 20-160 |
| Rated Duty Cycle | 60% | 60% |
| Applied Welding Rod(mm) | ¢1.6-4.0 | |
| Power Factor | 0.73 | |
| Efficiency(%) | 85 | |
| Insulation Grade | F | |
| Housing Protection Grade | IP21S | |
| Weight(Kg) | 6 | |
| (L*W*H)(mm) | 420*150*240 | |
| Carton CBM(m3) | 0.04 | |
| Specification | ||
| Â Capacitor | 2200UF\200V *4 | |
| IGBT | 40N60 *4 | |
| Output Rectifier | D92-02*6 | |
  Â
Â

Trade terms:
Payment Terms : 30% deposit , 70% balance after finish production
Delivery Date: 30-40days after receiving depositÂ
Shipment :Â by sea /DHL
Company profile:Â
Gubang is was awarded national high tech enterprise which is specialized  in  inverter  DC  welding  machine and  cutting  machine,  It was established in 2005 , "superior performance  with compatible  price" is  our  core    value.Â
Gubang have passed ISO9001 quality authentication and products have got CCC, CE,ROHS certificate
Products have been exported to more than 50 countries  and  regions  including  Europe,  America,  Africa,  Oceania, Middle East and Southeast Asia
Main products:Â
ARC welder, Tig welder, Mig welder, SAW, CutterÂ
Web: www.inverter-welding.comÂ
Â
Cell: +86 15818791557
Â
Performance and Features:Â Â Â Â Â
  1.110V/230V dual voltage input. Machine can identify the input voltage automatically.Â
  2. Advanced IGBT inverter technology, nanometer crystal transformer, stable and
reliable.
 3.Over heating protection, over current protection, anti-fluctuation of power voltage.    Â
 4.High duty cycle, high efficiency, low consumption , power saving, ideal DIY welder.
Â
  5.Hot starting, arc force, Anti-sticking, easy arcing, smooth welding and perfect
welding results.
Â
  6.Supplied complete with electrode holder, earth clamp and strong carton box.
Parameter/Specification:
 Â
Â
  1.110V/230V dual voltage input. Machine can identify the input voltage automatically.Â
  2. Advanced IGBT inverter technology, nanometer crystal transformer, stable and
reliable.
 3.Over heating protection, over current protection, anti-fluctuation of power voltage.    Â
 4.High duty cycle, high efficiency, low consumption , power saving, ideal DIY welder.
Â
  5.Hot starting, arc force, Anti-sticking, easy arcing, smooth welding and perfect
welding results.
Â
  6.Supplied complete with electrode holder, earth clamp and strong carton box.
Parameter/Specification:
| Model Item      |
ARC-160DC | |
| Voltage(V) | 1~AC110V | 1~AC230V |
| Frequency(Hz) | 50-60 | 50-60 |
| Input Power(KVA) | 5.3 | 6.8 |
| No-load Voltage(V) | 56 | 56 |
| Current Range(A) | 20-130 | 20-160 |
| Rated Duty Cycle | 60% | 60% |
| Applied Welding Rod(mm) | ¢1.6-4.0 | |
| Power Factor | 0.73 | |
| Efficiency(%) | 85 | |
| Insulation Grade | F | |
| Housing Protection Grade | IP21S | |
| Weight(Kg) | 6 | |
| (L*W*H)(mm) | 420*150*240 | |
| Carton CBM(m3) | 0.04 | |
| Specification | ||
| Â Capacitor | 2200UF\200V *4 | |
| IGBT | 40N60 *4 | |
| Output Rectifier | D92-02*6 | |
  Â
Â
   Trade terms:
Payment Terms : 30% deposit , 70% balance after finish production
Delivery Date: 30-40days after receiving depositÂ
Shipment :Â by sea /DHL
Company profile:Â
Gubang is was awarded national high tech enterprise which is specialized  in  inverter  DC  welding  machine and  cutting  machine,  It was established in 2005 , "superior performance  with compatible  price" is  our  core    value.Â
Gubang have passed ISO9001 quality authentication and products have got CCC, CE,ROHS certificate
Products have been exported to more than 50 countries  and  regions  including  Europe,  America,  Africa,  Oceania, Middle East and Southeast Asia
Main products:Â
ARC welder, Tig welder, Mig welder, SAW, CutterÂ
Web: www.inverter-welding.comÂ
Â
Cell: +86 15818791557
Â
Name
High purity palladium(Pd)
Chemical and physical properties
Palladium content 99.95%~99.99%
Specification ø50.8*3mm, ø76.2*3mm, or on request
Characteristic
High purity, low content of impurities, especially gaseous impurities; uniform crystal grains.
Good electrical conductivity; good ductility and plasticity, can be forged, calendered and drawn; strong resistance to air corrosion and acid corrosion at room temperature.
Pure Palladium,Purity Palladium,Pd Sputtering Target,High Purity Palladium Ingot
Shandong Hitech Metal Material Co., Ltd , https://www.sdhitech.com
