- Model No.: HSN & HAC
- Screw Suction Method: Single Suction
- Application: Metallurgy, Power, Petrochemical
- Structure: Rotary Pump
- Purpose: Lubrication, Transfer, Jacking
- Pressure: Medium Pressure
- Safety Valve: Pressure Relief Valve
- Color: Customizable as per Customer Requirements
- Trademark: RSP
- Specification: ISO 9001, CE, API 676
- HS Code: 8413604090
- Screw Number: Multi-Screw Pump
- Pump Shaft Position: Horizontal
- Certification: CE
- Principle: Positive Displacement Pump
- Medium: Lubricating Oil, Fuel Oil, Diesel Oil
- Capacity: Large
- Shaft Seal: Mechanical Seal, Framework Oil Seal
- Mounting Options: Horizontal, Vertical, Flanged, Submersible
- Transport Packaging: Standard Seaworthy Wooden Case
- Origin: China
- Viscosity: 3.0 ~ 760 mm²/s
- Flow Rate: 11 ~ 3500 L/min
- Maximum Pressure: 4.0 MPa
- Maximum Temperature: 120°C
Key Features:
1. Widely used in various industrial applications due to its reliability and efficiency.
2. Advanced design allows for easy maintenance and replacement of pump components.
3. Equipped with a unique dual-seal system for enhanced sealing performance and durability.
4. Integrated pressure relief valve ensures safe operation and protects the pump from overpressure.
Applications:
Ideal for transferring various lubricating or semi-lubricating fluids without solid particles, such as lubricating oils (including machine oil, hydraulic oil, gear oil), water glycol, lubricating grease, light diesel, residual fuel (like heavy oil, coal tar), and other viscous chemical media.
Commonly applied in machinery, petrochemicals, metallurgy, steel, power generation, marine, centralized lubrication systems, and lube circulation systems. Mounting Types:
- **H**: Horizontal mounting, connected via a standard baseplate
- **F**: Bracket-type mounting, using a supporting frame
- **S**: Vertical mounting
- **K**: Submersible mounting, designed to save space in oil tanks This multi-screw pump is a versatile and efficient solution for a wide range of industrial fluid transfer needs, offering reliable performance and long service life.
